PORTABLE X-RAY UNIT (Rat-98)

PORTABLE X-RAY UNIT (Rat-98)

The Rat-98 from Runyes gives dental professionals a portable radiographic imaging option that combines easy transport with the precise settings required in a modern clinical environment. From the start of your purchase decision, convenient installment plans are available through Tabby and Tamara in four payments, allowing you to upgrade your imaging equipment while spreading the purchase cost more flexibly. The RAY98(P) model has a compact form and weighs 1.7 kg, making it suitable for use inside the clinic or in mobile practices when approved operating and protection procedures are followed.

The unit operates with a tube voltage of 70 kV ± 10% and a tube current of 2 mA ± 20%. It uses a Canon D-045 X-ray tube with a 0.4 mm focal spot and an anode angle of 12.5+°. According to the product specifications, these features support clear radiographic images for diagnostic dental applications. The exposure-time range extends from 0.04 seconds to 2.0 seconds, giving qualified users flexibility to select the appropriate setting according to the case and the clinical protocol in use.

Rat-98 operates within a wide input range of 100 V to 240 V and a frequency of 50 Hz to 60 Hz, making it easier to use in different operating environments when a suitable power source is available. Its specifications indicate radiation leakage of 0.25 mGy/h at a distance of one meter. Despite the importance of these specifications, operation by dentists or trained professionals and adherence to radiation-protection protocols remain essential for every case. Accuracy in setup, positioning, and operation is what turns technical specifications into dependable clinic performance.

In daily use, the value of a portable design becomes clear when the dentist needs to arrange imaging smoothly within a busy schedule or a treatment environment requiring greater flexibility. Its compact weight supports mobility, while the exposure settings allow qualified users to adjust exposure according to each case. Through a clear operating display and organized preparation steps, the unit can help speed up the imaging process without overlooking accuracy and protection requirements.

Brand, Supplier, and Authenticity Documentation

The unit carries the Runyes brand and is available through the supplier YouJoy. If your facility requires independent authenticity documentation or confirmation of an exclusive agent, an official document can be requested before purchase approval. This step is important when equipping medical complexes or when institutional procurement requires supporting documents, helping you complete the purchasing decision with clarity.

Package Contents from the First Delivery

The package includes the RAY98(P) portable X-ray unit, a power cable, a user manual, and a warranty card. These items help ensure an organized start to operation, while the user manual can be retained as a reference for settings and device care. If you have additional requirements regarding accessories or charging arrangements, you can confirm the final shipment contents when ordering before preparing the workspace.

Compatibility and Operating Details

The unit is described as compatible, without listing specific software programs, sensors, or digital receptor systems. Therefore, if the clinic uses a particular imaging system, it is recommended to request compatibility confirmation before purchase. This gives you greater confidence that the unit will suit your existing equipment and helps avoid technical differences after delivery.

Before use, first ensure that the unit is connected to a suitable power source within the 100 V to 240 V range and that the power cable is in good condition. Set the exposure time between 0.04 and 2.0 seconds according to imaging requirements and approved clinical instructions, then position the X-ray tube correctly before activation. The device should not be used if there is visible damage or a functional fault, and the required professional distance and precautions must be observed during operation. After use, store it in a cool, dry place with relative humidity between 30% and 75% RH, and preferably keep it in its original packaging when not in use.

Warranty and Spare-Part Availability

The Rat-98 has a two-year warranty that includes spare parts, with spare parts available when needed. This means the purchase is not limited to receiving the unit alone; it also includes a clear support path to help maintain continued operation. Before confirming the order, you can inquire about warranty activation, how to request parts, and the steps followed when inspection or technical service is required, allowing the clinic to be prepared from the outset.

Maintenance, Installation, and Training in Saudi Arabia

Maintenance is available for the unit within Saudi Arabia, and the maintenance team serves all cities. Installation and training are also available to help the team receive the unit and start using it in an organized way. You can confirm service arrangements in your clinic’s city, options for sending the unit for maintenance, and installation or training appointments before purchase. These services help make the transition from delivery to daily operation clearer and more efficient.

Registration and Tax

The product is registered with the Saudi Food and Drug Authority (SFDA), and the required documents can be requested when internal approval or procurement documentation is needed. No VAT is listed for the product; however, it is preferable to confirm the VAT status and whether the final price includes it or is exempt from it before issuing the invoice and making payment.

Delivery, Quotation, Demo, and Payment

The expected delivery time is three to five business days and may vary depending on the city, stock availability, and shipping procedures. Therefore, it is best to confirm the actual delivery date before approving the order. An official quotation can also be requested, making it suitable for clinics that require administrative approval or plan to add a new unit to their equipment.

A real product demonstration video is not currently available, but a Demo can be requested to view the unit in operation and receive a direct explanation before purchase. In addition to Tabby and Tamara installments over four payments, an installment option can be requested. Financing or deferred-payment options specifically for clinics can be discussed when requesting an official quotation. Confirm compatibility, package contents, delivery, and invoice details, then choose the payment option that helps you add Rat-98 to your clinic with confidence and readiness.
